Adam Young: Shift on Stack: api_port failure

I finally got a right-sized flavor for an OpenShift deployment: 25 GB Disk, 4 VCPU, 16 GB Ram. With that, I tore down the old cluster and tried to redeploy. Right now, the deploy is failing at the stage of the controller nodes querying the API port. What is going on?

Here is the reported error on the console:

<figure class="wp-block-image"></figure>

The IP address of 10.0.0.5 is attached to the following port:

$ openstack port list | grep "0.0.5"
| da4e74b5-7ab0-4961-a09f-8d3492c441d4 | demo-2tlt4-api-port       | fa:16:3e:b6:ed:f8 | ip_address='10.0.0.5', subnet_id='50a5dc8e-bc79-421b-aa53-31ddcb5cf694'      | DOWN   |

That final "DOWN" is the port state. It is also showing as detached. It is on the internal network:

<figure class="wp-block-image"></figure>

Looking at the installer code, the one place I can find a reference to the api_port is in the template data/data/openstack/topology/private-network.tf used to build the value openstack_networking_port_v2. This value is used quite heavily in the rest of the installers' Go code.

Looking in the terraform data built by the installer, I can find references to both the api_port and openstack_networking_port_v2. Specifically, there are several object of type openstack_networking_port_v2 with the names:

$ cat moc/terraform.tfstate  | jq -jr '.resources[] | select( .type == "openstack_networking_port_v2") | .name, ", ", .module, "\n" '
api_port, module.topology
bootstrap_port, module.bootstrap
ingress_port, module.topology
masters, module.topology

On a baremetal install, we need an explicit A record for api-int.<cluster_name>.<base_domain>. That requirement does not exist for OpenStack, however, and I did not have one the last time I installed.

api-int is the internal access to the API server. Since the controllers are hanging trying to talk to it, I assume that we are still at the stage where we are building the control plane, and that it should be pointing at the bootstrap server. However, since the port above is detached, traffic cannot get there. There are a few hypotheses in my head right now:

  1. The port should be attached to the bootstrap device
  2. The port should be attached to a load balancer
  3. The port should be attached to something that is acting like a load balancer.

I'm leaning toward 3 right now.

The install-config.yaml has the line:
octaviaSupport: "1"

But I don't think any Octavia resources are being used.

$ openstack loadbalancer pool list

$ openstack loadbalancer list

$ openstack loadbalancer flavor list
Not Found (HTTP 404) (Request-ID: req-fcf2709a-c792-42f7-b711-826e8bfa1b11)

19 Jan 2020 12:55am GMT

18 Jan 2020

feedFedora People

Luigi Votta: No censorship! Please!

If I use an IT instrument as a blog, subscribed in a Planet I pretend immediatly to view on Planet!!! As my post has no need to censorship!

18 Jan 2020 10:14pm GMT

Luigi Votta: Ubuntu as Fedora!

At least if you are in an UBUNTU environment and like to build the docs, as I was in Samba:
Go in to docs directory and than:
(mine was a docs-xml)

sudo apt install build-essential
sudo apt install xsltproc
sudo apt install fop
sudo apt install docbook

sudo make all

DOCS are very very important to READ!
